Siemens Level Transmitters
Narrow beam angle of only 10°, Chemically resistant PVDF copolymer enclosure and CSM rubber face, Measuring range: 8 m (26 ft) for measurement of liquids and slurries. Fully submersible: IP68 degree of protection.
Measuring range up to 12 meters. Safe or hazardous area duty. ETFE or PVDF wetted parts. 4-20mA or profibus output. Ultrasonic Level Transmitter.
Temperature Max 200°C. Pressure Max 40 BAR. Range of 20 m (66 ft). Radar Level Transmitter.
Integral temperature compensation, Low ringing effect reduces blanking distance, Optional foam facing for dusty applications, Self-cleaning and low maintenance, Chemically resistant, Hermetically sealed, Ultrasonic Level Transmitter.
Monitors wet wells, weirs and flumes. Digital communications with built-in Modbus RTU via RS-485. Compatible with SmartLinx system and SIMATIC PDM configuration software. Single or dual point level monitoring. 6 relay (standard), 1or3 relay (opt.)
Outputs for alarms, chart recorders, controllers and integration of existing systems. Monitors wet wells, weirs and flumes. Energy-saving function with built-in real-time clock. Special control mode to reduce grease rings and other deposits.
Single/dual point level monitoring. False-Echo Suppression for fixed obstructions. Noise reduction and improved signal-to-noise ratio. Level, volume & flow measurements in open channels, differential control, extended pump control and alarm functions
4-20mA output. Accuracy 0.5% of measured valve. Max pressure 35 BAR. Max insertion length 10mt. Capacitance Level Transmitter.
4-20mA output. Accuracy 0.1% of measured valve. Max pressure 525 BAR. Max insertion length 35mt. Capacitance Level Transmitter.
The SITRANS LG series comes in four different models: LG240, LG250, LG260 & LG270 Technology: Guided wave radar Range: 300 - 75 000 mm Process Temp: -196 - +450C Vessel Pressure: -1 - +400 bar
4-20mA output. Measuring range 0.3-20 mt. Hart or profibus communication. Safe or hazardous area duty. Radar Level Transmitter.
SITRANS LR250 is your first choice for liquid level measurement in storage and process vessels up to 20 meters (66 ft).
SITRANS LR250 is your first choice for liquid level measurement in storage and process vessels up to 20 meters (66 ft).
High temperature. High pressure. to a range of 50 m (164 ft); Ideal for low dielectric media. Radar Level Transmitter.
Technology: FMCW Radar. Range: 100m. Process Temperature: -40 to 200°C (-40 to 392°F). Process Pressure: Up to 3BAR.
Safe or hazardous area duty. 4-20mA, Hart output. Liquids or slurries. Radar Level Transmitter.
Range: 0.25 to 5 m (0.8 to 16.4 ft). Process temperature: -40 to 60°C (-40 to 140°F). Output: One relay, 4 to 20 mA (3-wire) or 4 to 20 mA (2-wire).
HydroRanger 200 HMI is an ultrasonic level controller for up to six pumps and provides control, differential control, and open channel flow monitoring
MultiRanger 200 HMI is a versatile short to medium-range ultrasonic single and multi-vessel level monitor/controller for virtually any application in a wide range of industries.
Technology: Guided wave radar. Range: 22.5m (75 ft). Process Temperature: -196 to 427°C (-320 to 800°F). Process Pressure: Full vacuum to 431 bar g (6250 psi g), probe dependent
Technology: FMCW radar Range: 100m (329 ft) Process Temperature: -40 to 200 °C (-40 to 392 °F) Process Pressure: 0.5 bar g (7.25 psi g)
Siemens Level Transmitters are suitable for a whole host of non-contact technologies; the range includes Ultrasonic Level Transmitters and Horned Radar Transmitters for llquids and solids, together with Antenna Radar Transmitters for liquids and slurries (6Ghz) - all of which are EExia & Safe Area Certified, and have measuring ranges of up to 100 metres.
In addition to this, contact insertion technologies include Hart & Profibus communication features on both the Guided Wave Radar Level Transmitters and the Capacitance Level Transmitters - both lof which are suitable for use with liquids and solids. These precision-engineered components are capable of sustaining high temperatures and high pressure applications of up to 427C and 430Bar respectively, while a measuring range of up to 25 metres completes the list of capabilities across this imprerssive range.
