Ultrasonic Flow Meters

Pipe diameter DN 0.8- 80, Measuring range 0.3 - 10 m/s, Measuring error 10% of full scale up to full scale: ±0.4% of the measured value Fluid temperature maximum 0C +100°C.

Nominal sizes from 4' to 48', Operating pressure Max. 430 bar, Temperature of medium From -200 to 200°C, Transducer types O-ring, Flange, InLine Ultrasonic Flow Meter.

Nominal Sizes From DN 50 to DN 300, Operating pressure Max 40 bar, Temperature of medium From -10 to 160°C, Transducer types Integrated, InLine Ultrasonic Flow Meter.

Accuracy

Measuring range: Qp 15 to 36000 m3/h. Nominal size: From DN 50 to DN 1200 (2' to 48'). Accuracy:

Measuring range: Qp

Qp 15 to 36000 m3/h. DN 50 to DN 1200 (2" to 48"). Accuracy

Accuracy:

THIS PRODUCT IS NO LONGER AVAILABLE FROM 30TH MAY 2017 Being that the SITRANS FST020 clamp-on ultrasonic flow meter offers basic functionalities, it is considered an optimal and affordable alternative to more complex flow measurement solutions. To make product selection straightforward while still offering solutions that fit the requirements of the water and wastewater, HVAC, power, chemical and general process industry, the product configuration has been simplified. In turn, the SITRANS FST020 features a user-friendly design, a very competitive price and delivery times that are up to par with market expectations.

THIS PRODUCT IS NO LONGER AVAILABLE FROM 30TH MAY 2017 SITRANS F US clamp-on ultrasonic flow meters measure the flow of electrically conductive and non-conductive liquids. All flow meters offer easy installation, no pressure drop or energy loss, a wide turn-down ratio with no need to cut the pipe or stop the flow and a minimal maintenance since the external transducers do not require periodic cleaning.

THIS PRODUCT IS NO LONGER AVAILABLE FROM 30TH MAY 2017 SITRANS FUE1010 Clamp On Ultrasonic Flow Meter is a highly accurate clamp-on non-intrusive ultrasonic flowmeter for revenue grade thermal energy sub-metering and energy efficiency distribution monitoring, with a real time coefficient of performance (COP) for HVAC systems. The meter is available in single and dual channel or dual path configurations, with your choice of IP65 (NEMA 4X) dedicated wall mount or IP40 (NEMA 1) portable enclosures.

THIS PRODUCT IS NO LONGER AVAILABLE FROM 30TH MAY 2017 SITRANS FUG1010 clamp-on non-intrusive ultrasonic flow meter is ideal for natural and process gas applications, including checkmetering, allocation, production, storage and gas fired power station applications. The meter is available in single, dual and optional four beam configurations, with your choice of IP65 (NEMA 4X) or IP65 (NEMA 7) and IP66 (NEMA 7) explosion proof enclosures.

THIS PRODUCT IS NO LONGER AVAILABLE FROM 30TH MAY 2017 SITRANS FUH1010 clamp-on non-intrusive ultrasonic flow meter is ideal for applications carrying crude oil, refined petroleum or liquefied gas. It is available in single, dual and optional four beam configurations, with choice of IP65 (NEMA 4X) or IP65 (NEMA 7) and IP66 (NEMA 7) wall mount enclosures. The meter has two application areas: Volumetric flowmetering and mass/standard volume flowmetering.

THIS PRODUCT IS NO LONGER AVAILABLE FROM 30TH MAY 2017 The SITRANS FUP1010 clamp-on non-intrusive ultrasonic flow meter offers maximum versatility plus battery power for portable field use. It can operate in either WideBeam transit time or Doppler mode, making it suitable for virtually any liquid. The meter is ideal for general flow survey work where high accuracy is required and is available in single and dual channel or dual path configurations.

Nominal sizes From 4' to 160', Operating pressure Max. 40 bar, Temperature of medium From -20 to 200°C, In Line Ultrasonic Flow Meter.

THIS PRODUCT IS NO LONGER AVAILABLE Pressure Range: 0.30 up to 10 metres, Accuracy: +/ 0.25% of full scale, Resolution: +/- 3mm, Supply Voltage: 18-32 VDC or 110-230AC, Medium temperature: -40 up to +80°C.

Brass with Silicone Seals PPS, Sizes - DN15 - DN25, Connection - BSP or NPT External thread 3/4', 1' or 1 1/4'.
