Temperature probes – Our range includes platinum resistance thermometers (PT100), thermocouples and thermowells to suit. Manufactured to your specification, we have unlimited options with our Siemens and Status range and can offer bespoke designs to meet your exact specifications.

STATUS INSTRUMENTS STYLE 3 - TEMPERATURE PROBE / SENSOR Model Number: STYLE 3

7.9mm dia. st/st sheath x 75, 100, 150, 200,250mm immersion 3 wire Pt100 class B.

STATUS INSTRUMENTS STYLE 4 - TEMPERATURE PROBE / SENSOR Model Number: STYLE 4

6mm dia. st/st sheath, x 75, 100, 150, 200, 250mm immersion. 3 wire Pt100 class B. PTFE 7/0.2 Cu insulated cable (1 metre).

STATUS INSTRUMENTS STYLE 6 - TEMPERATURE PROBE / SENSOR Model Number: STYLE 6

6mm dia. st/st sheath x 50, 150, 305mm immersion. 3 wire Pt100 class B. 50mm, 150mm or 305mm immersion.

STATUS INSTRUMENTS SCH4 - CONNECTION TERMINATION HEAD Model Number: SCH4

Multi entry. Houses One or Two Transmitters. Sealed to IP67. Digital Display Option.

STATUS INSTRUMENTS STYLE 9 - TEMPERATURE PROBE / SENSOR Model Number: STYLE 9

6mm dia. s/s sheath x 75, 100, 150,200,250mm immersion. 3 wire Pt100 class B.

STATUS INSTRUMENTS SPP2640P - TEMPERATURE PROBE WITH BATTERY POWERED DISPLAY Model Number: SPP2640P

4 digit LCD display of temperature. Battery powered. Flexible immersion length. 6mm sensor diameter. Temperature range - 50/200 Deg C at tip.

STATUS INSTRUMENTS STYLE 8 - TEMPERATURE PROBE / SENSOR Model Number: STYLE 8

12.7mm dia. x 200mm long st/st sheath. 3 wire Pt100 class B. Flexible PVC sheath over cable, 3 wire 7/0.2 Cu PTFE. insulation, 1 metre long.

STATUS INSTRUMENTS STYLE 7 - TEMPERATURE PROBE / SENSOR Model Number: STYLE 7

12.7mm dia. x 50mm long st/st sheath. 3 wire Pt100 class B.

STATUS INSTRUMENTS STYLE 10 - TEMPERATURE PROBE / SENSOR Model Number: STYLE 10

6mm dia. s/s sheath x 75, 100, 150,200,250mm immersion. 3 wire Pt100 class B. 3/4'bsp process connection, (parallel male running nut). 12.7mm x 75mm extension.

STATUS INSTRUMENTS STYLE 11 - TEMPERATURE PROBE / SENSOR Model Number: STYLE 11

6mm dia. s/s sheath x 75, 100, 150,200,250mm immersion. 3 wire Pt100 class B. 3/4'bsp process connection, (parallel female running nut). 12.7mm x 75mm extension.

STATUS INSTRUMENTS STYLE 2 - TEMPERATURE PROBE / SENSOR Model Number: STYLE 2

6mm dia. st/st sheath x 75, 100, 150, 200, 250mm immersion. 3 wire Pt100 class B. For use with a compression fitting.

Showing 1 to 14 of 14 (1 Pages)
