Burkert Stainless Steel Instruments
Pressure 0.2 - 10 bar, Ports G1/2' - G21/2', Orifice DN 13 to 65 mm, Voltages 24, 110, 230 V/UC, Duty cycle 100% continuously rated, IP65, EEx m II T4 with moulded cable & EEx me II T4 with terminal box.
Port Connection: G 1/4, G 3/8, G 1/2. Body Material: Stainless steel, brass and stainless steel, nickel-plated. Seal Material: PEEK/FKM; PCTFE/FKM; PTFE/FKM. Max Pressure: 250 Bar. For high pressures. servo-assisted
Port size 1/4'. Pressure range 0-10 bar. Temperature media -10°C to + 90°C. Body material Brass, stainless steel. Seal material FPM, EPDM or Buna.
Pressure range 0.2 - 10 bar Port Connections Threaded port G1/2' - G21/2' Operating voltages 24, 110, 230 V/UC Duty cycle 100% continuously rated Rating IP65 Approvals: EEx m II T4 with moulded cable & EEx me II T4 with terminal box
Pressure Range: 0.2-10 bar, max, Body material: Brass or St/St, Seal material: NBR, EPDM or Viton fluoroelastomers, Separating diaphragm isolates solenoid from operating fluid Lockable manual override as standard.
Port Connection: G1/8, G1/4, G3/8, sub-base Body Material: Brass & Stainless Steel Seal Material: FKM, PTFE/Graphite & EPDM Pressure: 0 - 25 Bar Media temprature ranges covering '"10°C + 180°C
Press. 0 - 10 bar & Vaccum Ports G1/8' - G1/4', Voltage: 24, 110, 230 V/UC Duty cycle 100% continuously rated IP65 EEx m II T4 with moulded cable & EEx me II T4 with terminal box
Port size 1/4" - 2" Pressure range 0-10 bar, Temperature media ranges covering -30°C to +120°C Body material Brass or Stainless Steel, Seal material NBR, FKM, EPDM Options - Explosion protection Ex to Eurostandard.
At Fine Controls we pride ourselves on our technical knowledge and are confident in our abilities to assist you in selecting the correct stainless steel instrument from the Burkert range.
We also carry one of largest stocks of Burkert products in Europe, meaning in most cases we can deliver your order the next day!
Need assistance? If you have any questions regarding the Burkert range of stainless steel instruments or have a specialist application you’d like to discuss, get in touch online or call us on +44 (0) 800 328 8511.
