Fairchild Volume Boosters
Maximum Output Pressure 150 psig. Maximum Supply Pressure 250 psig. Flow Capacity SCFM @ 100 psig supply 45, 20 psig output. Sensitivity 1/4' Water Column. Pipe size 1/4' NPT - 3/8' NPT/BSPT.
Supply Pressure 250 psig Maximum. Output Pressure 150 psig Maximum. Flow Capacity (SCFM) 830 @100 psig, 20 set point. Sensitivity 1' Water Column. Pipe Size 1' NPT - 1 1/2' NPT.
Maximum Supply Pressure 250 psig. Maximum Output Pressure 150 psig. Flow Capacity (SCFM) 40 @ 100 psig & 20 psig set point. Sensitivity Less than 1' Water Column. Ratio 1:1 - 1:1.6. Pipe size 1/4' NPT - 3/8' NPT/BSPT.
Supply Pressure 250 psig Maximum. Output pressure 150 psig Maximum. Sensitivity 1' Water Column. Pipe size 1 1/2' NPT.
Maximum Output Pressure 150 psig. Maximum Supply Pressure 250 psig. Flow Capacity 150 SCFM @ 100 psig supply SCFM, 20 psig set point. Ratio 1:1 to 3:1. Pipe size 3/8 NPT - 3/4 NPT.
Supply Pressure 250 psig Maximum. Outlet Pressure 150 psig Maximum. Flow Capacity (SCFM)500 @100 psig inlet, 20 psig set point. Fixed deadband between operation of supply and exhaust valves for accurate and stable positioning.
Supply Pressure 250 psig Max. Outlet Pressure 150 psig Max. Very low deadand between the supply valve and exhaust valve. Flow Capacity (SCFM)500 @100 psig inlet, 20 psig set point. High Accuracy, sensitivity and excellent low pressure performance.
As the Official UK Distributor of Fairchild Industrial Products, Fine Controls carries the largest stock of Fairchild Products in Europe and our sales team is fully equipped to handle any enquiry from simple price and delivery to technical advice and system build requirements.
Need guidance around our Fairchild products?
If you feel you need guidance on selecting the correct Fairchild product for your application, please feel free to give us a call on +44 (0) 800 328 8511 and talk to one of our technical sales team.
