Burkert Fluid Controls provide a varied range of high-quality process valves suitable for application requirements from a wide range of industries. From slurries to steam and de-ionised water to hydrochloric acid, our extensive choice of Burkert valve types and sizes present a complete solution for your application. You can be sure in the knowledge that you have chosen valves manufactured with experience and quality.
Port size 1/2' - 2 1/2', Pressure range 0-16 bar, Temperature media -10-°C to +180°C, Body material Gunmetal, Stainless Steel, Options: Double-acting actuator, Weld-end connection, Electrical position feedback & Manual override.
Port Connection: G 1/2, G 3/4, G 1, G 1 1/4, G 1 1/2, G 2 Body Material: Gunmetal Seal Material: PTFE Max Pressure: 16 Bar Maximum Temperature 180°C Multi function
2/2-way Angle-Seat Valve with stainless steel design for media up to +185
Port Connection: G 1/4. Body Material: Stainless steel 1.4401. Seal Material: Stainless steel/PCTFE. Max Pressure: 250 Bar. Direct-acting, normally closed and normally open. Electrical connection cable plug Form A. Also available with ATEX approval.
2/2-way Angle-Seat Control Valve with stainless steel design for media up to +185 Port Connection: DN15 - 65 Body Material: 316L Stainless Steel Actuator: PPS Ambient Temperature: 0-55C
2/2-way Globe Control Valve with stainless steel design for media up to +185 IP65/67 protection class and superior chemical resistance Orifice: DN4 - 65 Body Material: Cast Stainless Steel 316L Actuator: PPS Ambient Temperature: 0 - 55C
Port Connection: G 1/4, G 3/8, G 1/2. Body Material: Stainless steel, brass and stainless steel, nickel-plated. Seal Material: PEEK/FKM; PCTFE/FKM; PTFE/FKM. Max Pressure: 250 Bar. For high pressures. servo-assisted
Port Connection: G 1/4, G 3/8, G 1/2. Body Material: Brass with stainless steel seat 1.4305 or stainless steel body 1.4581. Seal Material: FKM, PTFE (others on request). Max Pressure: 100 Bar. Maximum Temperature 180°C.
Input: 4-20mA, 0-20mA & 0-10V. Maximum operating pressure 16 bar. Body Stainless steel . Plug/stem Stainless steel. Integrated, cascaded process controller with parameter definable PID-algorithm. LCD/key pad,menu-guided program & code-protection.
THIS PRODUCT IS NO LONGER AVAILABLE Low Flow, 0-12 bar, DN 0.8 - 2.0 mm, 1/8' or sub-base version.
0-16bar, DN 0.8 - 4 mm, 1/8', 1/4' or sub-base, EEX approvals optional, Brass or ST/ST bodies.
Port size 1/4'. Pressure range 0-10 bar. Temperature media -10°C to + 90°C. Body material Brass, stainless steel. Seal material FPM, EPDM or Buna.
Port Connection: Flange, Body Material: Brass and stainless steel 1.4401, Seal Material: NBR, FKM (EPDM on request), Max Pressure: 16 Bar, Manifold Mounted, Manual Overide, Electrical feed back option.
Port Connection: G 1/2, G 3/4, G 1. Body Material: Brass, grey cast iron, Seal Material: PTFE/graphite, Max Pressure: 12 Bar, Maximum Temperature 180°C.
Port size 1/2'- 2'. Pressure range 0-10 bar, Temperature media -10°C to +180°C, Body material Brass (valve seat S.St.1.4303), Seal material PTFE.
Port size 1/2' - 2', Pressure range 0.2-16 bar, Temperature media -10°C to +90C, Body material Brass, Seal material NBR, Options - Manual override & Explosion Protection Ex to Eurostandard.
Pressure range 0.2 - 10 bar Port Connections Threaded port G1/2' - G21/2' Operating voltages 24, 110, 230 V/UC Duty cycle 100% continuously rated Rating IP65 Approvals: EEx m II T4 with moulded cable & EEx me II T4 with terminal box
Port size 1/2' - 1', Pressure range 1-50 bar, Temperature media -10°C to +90°C, Ambient temperature +55°C, max, Body material Brass, Seal material PTFE (O-rings NBR), Un-effected by pressure surges.
Flow rate 900 (I/min), Pressure range 1-10 bar, Manual override, 1/4 Ported.
Pressure range 2-8 bar Ports G1/8 & 6mm push in DN 13 up to 65 mm Body Polyamide Ambient temp -10 up to +50 °C 24 VDC Duty cycle 100% continuously rated IP65 ATEX EExia IIC T6
Compact Size, Brass or st/st, Manual Override , 1/8 or sub base mounted, 0-10bar.
Pressure Range: 0-10 bar, max. Temperature media: -10°C to +100°C, Body material: Brass or St/St, Seal material: FPM.
As the premier partner to Burkert Fluid Controls in the UK, Fine Controls’ holds extensive stock of the Burkert Valve range, including:
- Solenoid valves in 2/2, 3/2, and 5/2 way variations and miniature, proportional and hazardous area technologies.
- Process and control valves comprising piston and ball valves, angle seat valves, globe valves, diaphragm valves and electro-pneumatic control valves.
- Top and side mount positioners, timer units and banjo pilot valves
