Hazardous Area Solenoid Valves

Pressure range 2-8 bar Ports G1/8 & 6mm push in DN 13 up to 65 mm Body Polyamide Ambient temp -10 up to +50 °C 24 VDC Duty cycle 100% continuously rated IP65 ATEX EExia IIC T6

Pressure 0.2 - 10 bar, Ports G1/2' - G21/2', Orifice DN 13 to 65 mm, Voltages 24, 110, 230 V/UC, Duty cycle 100% continuously rated, IP65, EEx m II T4 with moulded cable & EEx me II T4 with terminal box.

Electrical 3mt moulded cable or terminal box. Port connections Threaded port

DN 8 & 9 Ports 1/4' BSP or NPT. Body Polyamide. Seals- NBR, NBR and PUR. Electrical connection With cable (3m length). Volts 24, 110, & 230 V/UC. Duty cycle 100% continuously rated. IP65. II 2G EEx m II T 5 PTB 00 ATEX 2129X II 2DIP 65T 100°C.

Fully st/st design, Ambient Temperature: -20°C to +40°C, 3/2 Closed, Open & Universal functions, IP67 rated.

Press. 0 - 10 bar & Vaccum Ports G1/8' - G1/4', Voltage: 24, 110, 230 V/UC Duty cycle 100% continuously rated IP65 EEx m II T4 with moulded cable & EEx me II T4 with terminal box

Body-Brass/stainless steel. Ports

Threaded port -

Ports

Fully st/st design, 3/2 & 5/2 Functions, Choice of Seal materials, Ideal of off shore applications.

Ports port

Pressure range 0.2 - 10 bar Port Connections Threaded port G1/2' - G21/2' Operating voltages 24, 110, 230 V/UC Duty cycle 100% continuously rated Rating IP65 Approvals: EEx m II T4 with moulded cable & EEx me II T4 with terminal box

Pressure: 0-10 bar max. Tech vacuum. Ports G1/8, G 1/4 and Sub-base connection. From -30 up to +40°C. Volts 24, 110, 230 V/UC. Duty cycle 100% continuously rated. IP 65. EEx-m-II T4, T5 and T6 or EEx-me-II T4, T5 and T6.

Pressure 0-16bar Ports DN1.5-DN2.0. Seals FPM. Body Polyamide/brass. Seal FPM(Viton). Electrical con. With cable/terminal box. Neutral gases. Voltage 24, 110, and 230 V/UC. Duty cycle 100% continuous rated. EEx-m-II T4 / T6 and EEx-me-II T4/T6.
