Pneumatic Instruments
Supply pressure 500 psig Maximum. Sensitivity less than 1/8' Water Column. Adjustment range 1-50"H20 to 15-450 psig. Pipe Size 1/8' NPT - 1/2' NPT/BSPT.
Output Range 0-120 psig Maximum Supply Pressure 150 psig Sensitivity 1” (2.5 cm) of water Air Consumption Less than 5 SCFM (0.17 m3/hr)
Supply Pressure 20 psig, ±2 psig for 3-15 psig output 30 psig, ±2 psig for 3-27 psig output Connections 1/4" NPT Output Capacity 0.16 scfm
Maximum supply pressure 80 or 150 psig. Repeatability 1% Adjustment range 2' W.C.-10 to 2.0-120. Inlet and Outlet 1/4"
Wall or panel mountable. +/-0.1% repeatability. 3-15psi output. Supply pressure effect 0.3% of span for 1PSi change.
Input Ranges 3-15, 3-9, 3-27, 0-15, and 0-30 psig including split Valve-Stroke Ranges 1/4" minimum -48" maximum Supply Pressure 3 psig min above full actuator pressure minimum 150 psig maximum
Output range 3-15 psig to 0-120 psig. Minimum Span 5 psig. Hysteresis & repeatability 0.25% FS. Flow rate (SCFM) 11 @ 150 psig supply & 9 psig output.
Output range (1:1 Ratio) 3-15 psig. Output Capacity (SCFM) 15 Maximum @ 20 psig supply, 45 @100 psig. Input Signal Various. Approvals: FM, CSA & CENELEC - Explosion-Proof & Intrinsically Safe.
Output Range Minimum 10' Water Column to 50', Maximum 0-150 psig. Output Capacity (SCFM) 40 Maximum with 100 psig, Booster Supply. Input Signal Various. Approvals: FM, CSA & CENELEC Intrinsically Safe.
Locks in Last Position. Accurately captures setpoint. IP65 Rating. Moisture resistant PCB.
Supply pressure 250 psig max. Flow capacity (SCFM) 150 . Sensitivity 1' Water Column. Adjustment range 0.5-10 psig.
Maximum signal pressure 200 psig. Minimum switching differential less than .1 psig. Maximum differential between signals 100 psig. Port size 1/4' NPT/BSPT.
Supply Pressure 250 psig Maximum. Output Pressure 150 psig Maximum. Flow Capacity (SCFM) 830 @100 psig, 20 set point. Sensitivity 1' Water Column. Pipe Size 1' NPT - 1 1/2' NPT.
Output range 3-15 psig to 0-120 psig. Input range 4-20mA DC, 0-10 VDC, 1-9 VDC. Flow Rate (SCFM) 11.0 @ 150 psig supply & mid scale output. Repeatability 0.1% Full Scale. Approvals: ATEX, FM, CSA & CENELEC - Intrinsically Safe & Non-Incendive.
Flow capacity 40 SCFM @ 100 psig supply, 20 psig set point. Sensitivity 1/2' Water Column. Supply Pressure 250 psig maximum. Output Pressure 150 psig maximum. Pipe size 1/4' NPT - 3/8' NPT/BSPT.
Flow capacity 14 SCFM. Pressure change under flow conditions less than 0.1 psig. Maximum supply pressure 250 psig. Maximum signal or output pressure 150 psig. Adjustment range 0-20 psig to 1-100 psig. Pipe size 1/8' NPT - 3/8' NPT/BSPT.
Supply Pressure 250 psig Maximum. Output Pressure 150 psig Maximum. Flow Capacity (SCFM) 150 @ 100 psig supply & 20 psig set point. Sensitivity 1' Water Column. Adjustment range 0.5-10 psig to 2-150 psig. Pipe size 3/8' NPT - 3/4' NPT.
Supply Pressure 250 psig Maximum. Outlet Pressure 150 psig Maximum. Flow Capacity (SCFM)500 @100 psig inlet, 20 psig set point. Fixed deadband between operation of supply and exhaust valves for accurate and stable positioning.
Supply / Output connection: ¼', ½' or ¾' NPT (F). Signal Connection: ¼' NPT (F). Supply Pressure: Up to 150 psig (10.3 bar). Pressure Ratio: 1:1. Operating Supply Gases: Air, Nitrogen, Methane (Natural Gas)
Flow capacity 40 SCFM @ 100 psi supply, 20 psi set point. Sensitivity 0.5' Water Column. Supply pressure 250 psi maximum, Out let pressure 150 psi maximum. Ratio range 30:1 through 1:30. Pipe size 1/4' NPT - 3/8' NPT/BSPT.
Adjustable bias over range -18 to + 15 psig. Input and output pressure range 3-15 psig. Maximum operating pressure: Signal and output 50 psig Supply 150 psig. Pipe size 1/4' NPT - 3/8' NPT.
Maximum supply pressure 120 psig. Signal range 2' Water Column to 120 psig. Repeatability 0.2' Water Column. Adjustment range 2' W.C.-10 to 2.0-120. Inlet and Outlet 1/4' 3/8'.
Maximum Output Pressure 150 psig. Maximum Supply Pressure 250 psig. Flow Capacity 150 SCFM @ 100 psig supply SCFM, 20 psig set point. Ratio 1:1 to 3:1. Pipe size 3/8 NPT - 3/4 NPT.
Supply Pressure 250 psig Max. Outlet Pressure 150 psig Max. Very low deadand between the supply valve and exhaust valve. Flow Capacity (SCFM)500 @100 psig inlet, 20 psig set point. High Accuracy, sensitivity and excellent low pressure performance.
Maximum Supply Pressure 250 psig. Maximum Output Pressure 150 psig. Flow Capacity (SCFM) 40 @ 100 psig & 20 psig set point. Sensitivity Less than 1' Water Column. Ratio 1:1 - 1:1.6. Pipe size 1/4' NPT - 3/8' NPT/BSPT.
Output Range 0-150 psig. Supply Pressure 0-200psig. Input Signal: Various.
Flow Cap. 40 SCFM @ 100 psig. Sensitivity 1/4' Water Column. Supply Pressure 250 psig max. Output Pressure 150 psig max.
Pneumatic Input Range 0-5 psig to 0-120 psig. Current Output 4-20 mA or 10-50 mA. Minimum Input Span 4 psig. Maximum Input Span 200 psig. Approvals: FM & CSA - Explosion-proof and Intrinsically Safe.
Output range 3-15 to 6-30. Minimum Span 5 psig. Flow Rate (SCFM) 9.0 @ 420 psig & 9 psig Output. Approvals: ATEX, CENELEC & SAA - Flame Proof and Intrinsically Safe.
Optional tapped exhaust port vents exhaust gas. Does not contain copper-based metals. Compact size for use in restricted areas. Optional version approved for use with Natural Gas or Industrial Methane as a supply media.
We've positive and negative bias relays, adjustable ratio relays, computing, snap acting and bias reversing relays to name but a few, as well as a comprehensive selection of Fairchild or Siemens Pneumatic Volume Boosters.
Add to this the selection of Fairchild & Siemens model I/P and P/I converters or transducers, and we're sure you'll be happy with the range on our website.
If it happens that you can't find the precise model you're looking for, our website does offer a search by part number function in the search bar above, or to make things even easier - let us find it for you!
You can contact our team of experienced engineers using our contact form, our live chat facility which should be showing around the bottom right of your screen, or on +44 (0) 800 328 8511
